direct replacement of TAC FORTA 800 AND SATCHWELL VALVES

---

Do you know that this actuator is a direct replacement of TAC FORTA 800 actuator and it has 1000N force ?

Also,  it can put it on Satchwell Valves ΜΖ / VZ with the additon of a linkage kit.

MVE510      202,00 €

MVE510-65 with  IP65         232,00 €

MVE510R with electronic failsafe function         286,00 €

MVE510R-65 with IP65 and  electronic failsafe function         316,00 €

AG-53 Linkage kit for Satchwell valves type VZ and MZ    35,00 €

Prices are subject to VAT 24%

Actuator for globe valve, 1000 N, 24 Vac / Vdc, IP54 or IP65 (-65 models).
U-bolt connection with long yoke.
Stroke from 5 to 60 mm.
Command : 3 point and 0..10 Vdc selectable.
Working fields 0 ÷ 10 Vdc, 2 ÷ 10 Vdc, 0 ÷ 5 Vdc, 5 ÷ 10 Vdc, 2 ÷ 6 Vdc, 6 ÷ 10 Vdc, 4 ÷ 20 mA.
Plug & Play and self-calibration in case of variations during operation.
